Operating instructions VS12 /C /F /F-P /W Maintenance
6.080.98.5.10.13 en 8 - 13
8
Product feed carriage VS12F
Fig. 53: Product feed carriage VS12F
Fix product feeding carriage in line with
guide shaft of product holder.
Remnant holder plate VS12, VS12F, VS12W
Fig. 54: Remnant holder plate
Attach remnant holder plate to product
holder by taking the fixation into ac-
count.
For quick and easy handling, the remnant
holder is attached to the pusher guard by
a magnet lock.
If the distance is less than
50 mm, pacemakers can be affected.
Place the product holder on the car-
riage.
Load plate VS12W
Fig. 55: Load plate VS12W
Fasten load plate in the holes by means
of the guide bolts and move it as far as
possible.
