BK Precision 9205B User Manual

23
Item
Parameter
9201B
9202B
9205B
9206B
Output
Voltage
0.0 V
0.0 V
0.0 V
0.0 V
Current
10.1 A
15.1 A
25.1 A
10.1 A
Protection
OVP, OVP
Voltage
OFF, 66 V
OFF, 66 V
OFF, 66 V
OFF, 156 V
OCP, OCP
Current
OFF, 11.1 A
OFF, 16.1 A
OFF, 26.1 A
OFF, 11.1 A
Beep
Mode
ON
ON
ON
ON
Max Volt
Limit
61 V
61 V
61 V
151 V
Comm
Interface
RS-232
RS-232
RS-232
RS-232
3.5 LIST Menu
All setup procedures and settings explained in this section can be accessed from the LIST SET
menu. To access this menu, press and . Use the keys to select LIST SET and
then press .
This menu configures the List mode function of the power supply. List mode allows you to
create a sequence of steps, store it into the power supply’s non-volatile memory, and execute it.
The input parameters for generating a list include voltage, current, and time value of each step.
Up to 10 list files can be stored, each allowing a maximum of 150 steps.
Enable/Disable List Mode
The initial LIST mode state of the power supply can be configured by following the steps below:
