Blastrac 500 E Global - Recovery Duct

108 pages

Save Page as PDF

To Next Page

To Previous Page

Operating Instructions 500 E Global

Spare parts

Recovery duct

Fig. 10.5

Item Part no. Description Qty.

1 E03509 Recovery duct 500E Global 1

2 E03191 Weight box 1

3 E03185 Weight for 500E Global 4
