Operating Instructions 500 E Global
General
4
3.5 Scope of supply
Scope of supply of the machine:
Blast cleaning machine (500 E Global)
Dust hose
Operating instructions (2 x)
Maintenance box (option)
Magnetic broom (option)
3.6 Description
Fig. 3.1
1 Fan unit 6 Blast housing
2 Abrasive separator 7 Recovery duct
3 Control box 8 Blast head, rubber sealing, brush sealing
4 Blast wheel motor 9 Recovery duct
5 Traction drive 10 Hose connection
