Blastrac 500 E Global - Blast Housing and Seals

Operating Instructions 500 E Global
Spare parts
2
Blast housing and seals
Fig.10.1
Item Part no. Description Qty.
1 - Bolt M10x55 + 2 x nut M10 3
2 500-1058-SE Front locating plate inner/outer 2
3 500-1054-SE Front skirt outer 1
4 - Front seal angle (part of blasthousing) 1
5 500-1053-SE Front skirt intermediate 1
6 500-1057-SE Front skirt fixing plate 1
7 500-1052-SE Front skirt inner 1
8 500-2010-SEH Front wheel castor 1
9 500-1020 Side seal (set of 2) 1
10 500-1021-SE Side seal spring plate 2
11 - Bolt M6x25 + washer + spring lock washer 8
12 500-1050-S Side brush (set of 2) 1
13 500-1061-SE Side skirt fixing plate 2
14 500-1060-S Side skirt (set of 2) 1
15 500-1045-S Back brush 1
16 500-9006-E Blast housing cabinet 1
17 500-1115 Top liner cover 1
