3.10 Separator and hopper
The abrasive separator is mounted to the end of the recovery duct. It
separates the abrasive from contaminants and feeds the cleaned
abrasive onto the abrasive storage hopper.
Fig. 3.7
1 Separator
2 Baffle plates
3 Hopper tray
4 Deflection plate
5 Abrasive storage hopper
6 Shot valve handle
7 Shot valve
