Blastrac 500 E Global - 1.3 Operative range and correct usage

500 E Global Operating Instructions
Technical data
3
Rated speed Enclosure
Drive of blast wheel 3480 min
-1
(60Hz) IP 55
Fan motor 3430 min
-1
(60Hz) IP 55
Drive motors 1700 min
-1
(60Hz) IP 55
Blast wheel size : 349 mm Ø
Working width : 500 mm
Drive speed : 0 - 15 m/min
Blast cleaning output on steel : up to 75 m²/h
Dust hose connection : 150 mm Ø
Recommended abrasive : Shot 390-460 / SG18-16-14
Abrasive consumption : 0,1 - 0,5 kg/m²
Recommended filter unit : Contact Blastrac for a
suitable Blastrac filter unit
1.3 Operative range and correct usage
The 500 E Global is exclusively designed to clean
dry, frost-free horizontal surfaces. The machine may
not be used for other purposes. The manufacturer
will not be liable for damage resulting from such
incorrect usage. In these cases the user assumes all
risks.
