Blastrac 500 E Global - 3.11 Drive system

Operating Instructions 500 E Global
General
12
3.11 Drive system
The drive is an independent electric system contained within the ‘V’ of
the blast housing cabinet. There is an On/Off switch on the electrical
panel to operate this drive control system.
Fig. 3.8
1 Control box
3 Drive wheel system left
4 Drive wheel system right
