500 E Global Operating Instructions
General
9
The shot valve handle
This handle is located at the right side of the hopper and regulates
the shot valve to control the flow of abrasive towards the blast wheel.
When the handle is pulled upwards, the shot valve is opened and
abrasive is allowed to travel towards the blast wheel in a progressive,
controlled manner.
Fig. 3.5 Shot valve OPEN/CLOSE
