500 E Global Operating Instructions
Spare parts
11
Drive system
Fig. 10.7
Item Part no. Description Qty.
1 500-3011-E Drive motor 2
2 500-1125-E Drive motor shaft 2
3 222-2021-E Drive motor sprocket 2
4 500-9129-E Drive motor plate outer left 1
5 500-9131-E Drive motor plate inner left 1
6 500-9130-E Drive motor plate outer right 1
7 500-9132-E Drive motor plate inner right 1
8 500-2425-E Drive wheel 2
9 500-1135-E Bearing flange drive wheel shaft 4
10 222-2331-E Drive wheel bearing 4
11 500-1130-E Drive wheel shaft 2
12 222-2023-E Drive wheel sprocket 2
13 222-2301-V Taperlock bush 2
14 500-2213-E Drive motor duplex chain 2
15 500-9105-E Rear wheel drive chain guard 2
