Bluebird VF550 - Function

7 Applications
65
1
If some values are changed and Exit program without press ‘‘Save’’ button , notice dialog will be popped
up.
2
Click Yes, App is closed.
3
Click No, remain in App.
7.10.1 Function
Name Type Description
Prefix Input text
Value added to the beginning of read data (e.g. 12345678).
Ex) if set text of abc, output would be – {}, {abc12345678}, {}.
Suffix Input text
Value added to the end of read data.
Ex) if set text of def, output would be – {}, {12345678def}, {}.
Sound Mode Select spinner on/off On/Off barcode beep sound.
Trigger Mode Select spinner
Beam Mode Option
• Level : Beam is on while scan button is pushed and held.
• Pulse : Beam is on till decoding Timeout time once scan button
is pushed.
• Edge : Pushing the button once, beam turns on. Pushing once
again, beam turns off.
• Autostand : The same as Edge, but beam is not off after data
is read. (keep reading data till trigger off is transmitted.)
• Streaming : Similar to Autostand, but works while the scan key
is pressed and stops when the key is released.
Aimer Mode Select spinner On/off the Aimer (+ shape laser).
Illumination
Mode
Select spinner On/off the Illumination (white light ).
Decode Timeout
Input text
Time set to stop reading after trigger on.
Min : 500ms / Max : 10000ms / default : 3000
Preamble
Input text
Value added to the front buffer.
Ex) if set text of abc, output would be - {abc}, {12345678}, {}.
Post amble
Input text
Value added to the back buffer.
Ex) if set text of def, output would be – {}, {12345678}, {def}.
Data wedge
Mode
Select spinner On/Off the Data Wedge Mode.
