Remove screws 1.
Disengage side panel 1 from
locators 2 and 3.
Slightly raise the side panel at
position 4 and remove.
Installing side panel
The procedure for the left
side panel is described
here, but the description applies
by analogy to the right side panel
as well.
Seat the side panel in mount 1.
Tilt the side panel up and push
it into locators 2 and 3.
Install screws 1.
Close lid 2.
Install screws 1.
9
99
z
Maintenance
