Technical specications
Specications 180 Multiprocess 200 Multiprocess
Part No. BOC180MULTILCD BOC200MULTILCD
Input voltage Single phase 240 V ±15 % Single phase 240 V ±15 %
Frequency 50/60 Hz 50/60 Hz
MIG TIG MMA MIG TIG MMA
Maximum rated input current (I
1max
) 25 A 17 A 26 A 27 A 20 A 30 A
Maximum e󹟽ective supply current (I
1e󹠢
) 9.7 A 6.6 A 10 A 12.1 A 8.9 A 13.4 A
Output current adjustment
30–180 A 10–180 A 10–180 A 30–200 A 10–200 A 10–200 A
No-load voltage U
0 78 V 78 V 78 V 78 V 78 V 78 V
Duty cycle (40˚C) @ 15% 180 A 180 A 180 A — — —
@ 20% — — — 200 A 200 A 200 A
Wire feeder Internal Internal
Internal wire feeder speed 2 to 13.6 m/min 2 to 13.6 m/min
Post ow time 3 Seconds 3 Seconds
Welding wire diameter 0.6/0.8/0.9/1.0 mm 0.6/0.8/0.9/1.0 mm
E󹟾ciency 82 % 82 %
Power factor 0.99 0.99
Insulation grade F F
Housing shielding grade IP23S IP23S
Suitable welding thickness >0.8 mm >0.8 mm
Min. generator rating 7 kVA 9 kVA
Dimensions (L × W × H ) 523 × 260 × 412 mm 523 × 260 × 412 mm
Weight 16.8 kg 16.8 kg
Standards AS/NZS 60974-1, IEC 60974-10 AS/NZS 60974-1, IEC 60974-10
Specications Spool gun
Rated current
150A/CO
2
130A/MIX
Duty cycle 60%
Cool Gas cool
Connecting socket Euro type
Wire spool diameter D100
Standard cable length 3 m
Motor voltage DC 24V
Speed adjusting potentiometer 10kΩ
Rated voltage ≤113V
