11.1.1 Logic Board (Removal)
1. Gain access to the logic board. This is normally done by removing the electronics cover or rear access
panel.
a. Lemur & Lemur-K (plastic cabinet) - Remove 4 Philip head screws and 1 hex head ¼” screw.
b. Lemur, Lemur-K & Lemur-2 (metal cabinet) - Remove all screws that hold enclosure &
electronics cover in place.
c. Lemur-S (metal cabinet) – Remove 5 Philip head screws from access panel.
d. Lemur-S (plastic cabinet) – Remove 3 Philip head screws from access panel.
e. Lemur-2P (metal cabinet) – Remove 4 Philip head screws from access panel.
2. Denote where all the cables are plugged into the logic board.
3. Unplug connectors connected to the main logic board.
4. Remove the four 3/16” head screws that secure the logic board onto the cabinet.
5. Lift board and remove.
11.1.2 Logic Board (Installation)
1. Installed the logic board into the printer.
2. Install the four 3/16” head screws that hold the logic board onto the cabinet and tighten.
3. Attach connectors going to the main logic board.
4. Install the electronics cover or rear access panel.
