Boca Systems Lemur - Spare Parts List

20
12.0 Spare Parts List
#
Part Number
Description
1
422557-25
Cable Ribbon, Thermal Head
2
420881Z-1
Enclosure, Lemur
3
423552-L
Cutter Assembly for all Lemurs except Lemur-R
3A
423552-LP
Cutter Assembly all model Lemurs except Lemur-R (PLASTIC CAGE ONLY)
3*
423552-R
Cutter Assembly for Lemur-R only
4
423759
Display Holder
5*
P50-1003
Drive Belt, 102T (for 300dpi)
5
P50-1017
Drive Belt, 98T (for 200dpi)
6*
P51-1011
Drive Pulley, 30T (for 300dpi)
6
P51-1007
Drive Pulley, 20T (for 200dpi)
7
P51-1014
Drive Pulley, 20T (for 200dpi & 300dpi)
8
423480Z
Upper Exit Deflector
8*
423480Z-VL
Upper Exit Deflector (vertical mount Lemur only)
9*
423485-VL
Lower Exit Deflector (vertical mount Lemur only)
10
423192
Ground Strap
11
423793
Energy Star Decal
12
422888-115
Transformer (110VAC)
12*
42288-230
Transformer (230VAC)
13
FGLZ46
Main Logic Board (Standard)
13*
FGLZ46-E
Main Logic Board (Ethernet option)
14
P46-110
Power board, 110VAC
14*
P46-220
Power board, 220VAC
14*
DC24A
Power board, 24VDC
15
423764
Opto Detector Assembly (opto)
15A
SQ OPTO
Opto Detector Assembly (opto) printers built August-2013 & later
16
423760-L3B-1
Platen (RADJW, ADJ2 & ADJW)
16*
423760-L4B-1
Platen (ADJ4 & RADJ4)
17
423789
AC Filter
18
2003
Print Head (200dpi RADJW, ADJ2 or ADJW)
18*
3003
Print Head (300dpi RADJW, ADJ2 or ADJW)
18*
2004
Print Head (200dpi ADJ4 & RADJ4)
18*
3004
Print Head (300dpi ADJ4 & RADJ4)
19
423496
Head Mounting Plate
19A
423496-5
Head Mounting Plate, plastic print cage ONLY
20
422590
Stepper Motor
21
P28-1020
Switch, Ticket Load
22
AC161A5
LCD Display
23
423236-2
Take Out Head Cam Lock
24
5316H
Control Panel Decal
25
421932-DSP
Fill-in Plate, Display
*25
423921
Fill-in Plate, Display (for plastic electronics box)
26
423559Z
RFI Cutter Shield
27
422521
Electronics Box, Lemur & Lemur-K (metal)
28
423565
Dust Cover, Cutter
29
P62-1006
Anti Static Brush
30
422521Z
Electronics Box, Lemur-2 & Lemur-2K
31
423792
Shoulder Bearing, Platen
32
423790
DC Out Cable, Power Board
33
423791
AC Out Cable, Power Board
34
423767
UL Cover, Power Board
35
P45-1009
Bearing (Large)
36
423917
Switching Power Supply (SPS)
37
423886-SPS
UL Shield (SPS
38
423791-SPS
AC Out Cable, SPS
39
P46M
Switch, Power for SPS
40
423789-SPS
AC Filter for SPS
41
423790-SPS
DC Out Cable, SPS
42
423895
Cover, Lemur (Plastic)
43
423894
Electronics Box, Lemur & Lemur-K (Plastic)
44
420881Z-2
Cover, Lemur (metal)
*
420881Z-Plus
Cover, Lemur-S
*
420881Z-Dual-2
Cover, Lemur-2
*
420881Z-Dual-2
Enclosure, Lemur-2
*
423825-2x6
Hopper, 2” wide ticket stock (cutter)
*
423825-4x6
Hopper, 2.5” to 4” wide ticket (cutter)
*
421421Z
Top Plate, vertical Lemur with cutter (8.70” x 9.64”)
*
421421Z-NC
Top Plate, vertical Lemur without cutter (13.00” x 9.48”)
*
421421Z-PA
Top Plate, vertical Lemur with cutter (10.25” x 10.25”)
