Changing Ethernet settings if your printer has a LCD display
CHANGING ‘ETHERNET’ SETTING
1. Please follow these steps to change the ETHERNET setting on your Ethernet printer.
2. Depress both the MENU and CHOICES buttons while turning on the printer. Keep both buttons depressed unit
FACTORY MENU appears in the LCD window or the display starts scrolling through different topics.
3. Using the MENU button scroll down to the ETHERNET?
4. Using the CHOICE button select the choice you want.
5. Press the TEST button to enter that setting.
6. Now the display will show EXIT AND SAVE. Press the TEST button to save the setting entered.
7. Note: if you selected ‘YES’ then you can use the default IP of 10.0.0.192 or set a different one as described next.
CHANGING ‘IP ADDRESS’
1. Please follow these steps to change the fixed IP address on your Ethernet printer. Note: if using a fixed IP
address make sure the ‘ETHERNET’ setting is set to ‘YES’ (see above).
2. Depress both the MENU and CHOICES buttons while turning on the printer. Keep both buttons depressed until
FACTORY MENU appears in the LCD window or the display starts scrolling through different topics.
3. Using the MENU button scroll down to the IP ADDRESS? and press the CHOICE button.
4. The blinking cursor indicates the current IP numeric value selected. Every time you press the CHOICE button the
numeric value will change.
5. Using the TEST button will move you over to the next numeric value.
6. Continue steps 4 & 5 to program the desired IP address value.
7. At the end the display will show EXIT AND SAVE. Press the TEST button to save the IP address you just entered.
CHANGING 'SUBNET MASK' SETTING
1. Depress both the MENU and CHOICES buttons while turning on the printer. Keep both buttons depressed until
FACTORY MENU appears in the LCD window or the display starts scrolling through different topics.
2. Using the MENU button scroll down to the Subnet Mask? and press the CHOICE button.
3. Each time you press the CHOICE button a different mask value will be displayed.
4. Once you have the mask value you want, press the TEST button. The display will show EXIT AND SAVE. Press
the TEST button a second time to save the address value.
CHANGING 'DEFAULT GATEWAY' ADDRESS
Follow same procedure as 'Changing IP address' above but in step 3 scrolls down to the DEFAULT GATEWAY.
CHANGING 'DNS SERVER' ADDRESS
Follow same procedure as 'Changing IP address' above but in step 3 scrolls down to the DNS SERVER?
