21
8.3 Viewing the circuits
1/ Select the number of the circuit you wish to view with the key.
2/ Select DISPLAY mode with the and keys.
3/ Validate with the key .
The display of the parameters is xed and the step
numbers ash.
The and keys can be used to scroll through all the program steps.
Use the key to exit from the menu at any time.
The program steps are displayed in the order of the times and then by type: weekly order,
holidays, special and then PC.
Steps 01 to 99 are indicated with the total number of steps; if the step is greater than 99 then
only the step number from 001 to 500 is displayed.
8.4 Programming the circuits
1/ Select the number of the circuit you wish to program, or modify the programming with the
key.
The circuits can be programmed in the following modes:
- Weekly,
- Holidays,
- Special,
- Public holidays,
- Additional step,
- Astronomical,
- Periodic.
Only the rst 4 modes are accessible from the master clock. All the modes are accessible from
the PC software.
2/ Select PROG mode with the and keys and validate with the key.
If the rst step is blank, the time ashes.
3/ Enter the time with the and keys and then
validate with the key.
4/ Proceed in the same way for the minutes and then the seconds.
Cir.01:08:02:00 03s
MTWTFS- Weekly 01/12 ú
Cir.01:HH:MM:SS --- ú
MTWTFS- Weekly 01/01 ok
