40
XV - Technical characteristics
Designation Characteristics
Electrical
Backup
Permanent backup of all parameters in case of mains failure. Automatic
resetting of receiver clocks to correct time after mains restoration.
Time base Quartz, accuracy 0.1 seconds per day between 20 and 25°.
Capacity 500 program steps per circuit.
Power supply 100-240 VAC 50/60 Hz
Maximum consumption 100-240 VAC ; 0,8-0,55 A.
Power supply terminal block
Rack: rigid or exible cable with end piece with cross section 1² to 1.5²
Wall-mounted: rigid wire 1² to 1.5² bared 6 mm.
Other terminals Cross section 1.5² maximum, bared 6 mm.
Electrical isolation Class 1.
Mains power supply system TT or TN system.
Relays
Control of 3 relays Programmable in weekly or annual mode
Control circuit (relay)
isolation
Galvanic isolation.
Circuit operating voltage
Either SELV* or LV** with common phase (230 V maximum between
the 2 circuits).
Relay breaking capacity 1A / 240 VAC.
Usefulness of indicator light
(of each circuit)
1) Lit when contact closed.
2) Used to indicate the current circuit programming.
Relay statuses
Standby/work on circuit 3.
Normally open on circuits 1 and 2.
Outputs
Synchronisation Depending on model, on DCF, MSF or GPS antenna.
Mechanical
Protection index Wall-mounted : IP41 / Rack : IP 20
Operating temperature 0 to 50°C
Keypad locking By access code
Dimensions
WALL-MOUNTED version 19» RACK Version
Width 220 mm 483 mm (1 width)
Height 322 mm 44 mm (1 U)
Depth 83 mm 200 mm
Weight 1.2 kg 1.4 kg
* SELV: safety extra low voltage (voltage < 42.4 V peak or 60 V continuous).
**LV: low voltage > 42.4 V peak or 60 V continuous.
