31
11.4 Relay setting menu
This menu can be used to assign the relays (D1D2
and alarm).
To go to the master clock relay assignment menu, validate
the option in the technician menu with the key.
The following screen is displayed :
By default, relay 3 (R/T relay) is assigned to the “Alarm”
output.
Note: when no alarm is active, the alarm relay is set to ON.
To allow it to be used for another function (control of heating, lighting, etc.), these relays must be
set to No in this menu.
The relay option boards are recognised immediately on connection in the master clock. If the
board is removed the programming is retained. It is deleted either with the PC software or in the
technician menu with the “Del.” option.
The assignment of the hard-wired relays is automatic. If a relay board is connected, the 3 relays
will be dened according to the following logical output number :
Slot 1, relays 4, 5 and 6,
Slot 2, relays 7, 8 and 9.
11.5 RHF circuit function setting menu
This menu can be used to assign the HF relays (16 address
1
maximum).
To go to the master clock relay setting menu, validate the
option in the technician menu with the key.
The following screen is displayed :
Assign the RHF circuits to melody, relay or —- (not
present) mode, MEL, REL, or, —-.
The RHF circuits are declared from 60 to 75.
1 Please note: several relays can be congured on the same address (for example for the same
external lighting control).
Relay setting ok
RHF Circuit õ
Rel. 3 alarm :Yes ú
ok
RHF Circuit ok
Function setting õ
CIR.RHF:60 > MEL ô ú
ok
CIR.RHF:60 > REL ú
ok
