17
P073GUI001 - e-Celsius Medical Connect System User Manual.4 - EN
Protection Index (IP): X8 (Matériel supportant l’immersion prolongée)
Alimentation: X8 (Material supporting prolonged immersion)
Power supply: Autonomous system containing zinc-silver oxide batteries.
Autonomy: 20 days
Contact time with the person: 2±1.5 days on average, up to 6 days depending on individual gastrointesti-
nal motility characteristics. If the capsule is not expelled after this period, please refer to point 8. End of
follow-up of the user manual.
Communication frequency: ISM band 433MHz - 434MHz
Radiated power: -22 dBm
Plastic: PVC free
Shelf life: Refer to the expiration date indicated on the blister pack
Transport and storage conditions: refer to table 1
The Activator (Fig. 3) is designed to activate an e-Celsius® Medical capsule before a measurement
cycle.
Figure 3: Activator
The wristband is attached to the wrist before ingestion of a capsule and is removed after expulsion of the
capsule (Fig. 1). A wristband is provided for each delivered capsule. These wristbands are located in the
box with the capsules. They are used to inform the health care personnel that the person has ingested a
capsule and is therefore not allowed to undergo an MRI examination.
It should be noted that in case of consecutive ingestion, the bracelet is removed when the last
capsule is expelled.
THE SIGNAL BRACELET
THE ACTIVATOR
