BodyCAP e Celsius - The Buttons; The LED; The Battery

23
P073GUI001 - e-Celsius Medical Connect System User Manual.4 - EN
WARNING: Modication of the electromagnetic device is prohibited
A Cyan LED is present on the upper face of the watch.
When the LED ashes, it indicates either:
- rapid ashing: a new alert is present (turning on the display allows to identify the type)
- slow ashing: the alert is still present but already displayed.
The watch has 2 buttons with different functions.
Button 1:
Long press: - turns on the watch if it is off
- sets a marker if the watch is already turned on
Short press: - turns the screen on or off
- Conrm a message to return to the main screen (time)
Bouton 2:
Long press: Starts the Bluetooth pairing (BLE) if the watch is not already connected.
Please do not forget to charge the battery at the end of those 5 days to avoid the risk of
losing the connection and conguration to all capsules in operation.
Information
The watch is equipped with a rechargeable battery of the Lithium-Polymer type. It is strictly forbidden to
disassemble the watch and replace the rechargeable battery, as this may cause irreparable damage to the
system and safety defects.
Recharge cycle
To charge the battery, you will just have to plug the power cable of the watch and connect the USB to a
suitable power supply or a computer USB socket. It takes a few hours to charge the battery. The autonomy
of the e-Med Connect watch in battery operation is about 5 days in normal operation and 3 days in
continuous alarm.
Charge time: ≈ 3 h.
Autonomy: ≈ 5j
IP rating: 67
Communication frequency:
ISM 433MHz ›› 434MHz.
Bluetooth Low Energy 4.x ou 5.x
Lifetime: 2 years (or about 500 recharge cycles).
Transport and storage conditions: refer to table 1
Means of disconnecting the power supply: Disconnect the power cable
Power Input: 100-240V~ 50/60Hz
THE BUTTONS
THE LED
THE BATTERY OF THE e-MED CONNECT WATCH
