BodyCAP e Celsius - Ingestion of the Capsule; View Temperature Data in Real Time

30
P073GUI001 - e-Celsius Medical Connect System User Manual.4 - EN
The e-Celsius® Medical capsule is now ready to be ingested by the patient, with a glass of water, for
gastrointestinal core temperature measurement. Please observe the claims of use and contraindications
presented on page 8. The application of the signal bracelet (Fig. 2) is followed by the ingestion of the
capsule. The e-Med Connect watch must also be installed on the patient's wrist in order to collect and
transmit all data to the application. The direction of the watch does not matter, but for the wearer's comfort,
it is recommended to position the BodyCAP logo on the arm side and not on the hand side.
In order to consult the collected temperature data, the watch and the application must be able to
communicate via BLE. Select the prole you wish to view.
The information on the main page is as follows:
* The prole name (0123456789ABCDEF)
* The BLE connection active/inactive (connected
* The last data collected (23.44°C) by the associated capsules
* The date and time of this data (03:04 PM 2021-02-11)
* Watch battery level (90%)
* The presence of a physiological alarm if applicable ( ) for at least one
of the active capsules
* The number of activated capsules (1 red )=> click on the capsules
allows a status display by capsule (unfold/unfold the status)
The prole temperature is the last temperature received for all capsules
associated with the watch at the same time. In the case where capsule
details are displayed, each capsule will display its own data and status. The
capsule symbol can be accompanied by one of the following icons:
Free space
Location occupied by an active capsule
Location occupied by a capsule in pause mode
Location occupied by an active capsule but with radio
connection (Capsule/Watch) issue
INGESTION OF THE CAPSULE
CONSULT THE TEMPERATURE DATA IN REAL TIME
Figure 13 - Consultation of temperature data
)
23.4423.44
