22
P073GUI001 - e-Celsius Medical Connect System User Manual.4 - EN
Button 1
Button 2
LED
Figure 6 - eMed Connect Box Description
Dimensions : Length: 52 mm
Width: 25 mm
Thickness: 15 mm
Weight: ≈ 33g (boiter & bracelet)
Screen: 128 x 32pixels
Operating temperature: 5-40°C
Data storage: 152,916 measurements per activated capsule
Power supply: Lithium-ion battery rechargeable with a dedicated micro-USB cable supplied with the system.
It is required to use a power supply conforming to IEC 60601-1 or IEC 62368-1 ( 5V / 1A ).
DESCRIPTION OF THE EQUIPMENT
THE CHARACTERISTICS
"Follow the instructions for use"
"Humidity level"
"Atmospheric pressure"
"Medical Device according to Regulation 2017/745"
"FCC ID"
"Do not use if packaging is damaged"
"Electronic manual"
"Keep out of reach of children"
