737 Operations Manual
Performance Inflight -
Engine Inoperative
737-400/CFM56-3_23.5K
Copyright © The Boeing Company. See title page for details.
D6-27370-400E-TBCE PI.23.9
ENGINE INOP
MAX CONTINUOUS THRUST
Long Range Cruise Diversion Fuel and Time
Ground to Air Miles Conversion
Reference Fuel and Time Required at Check Point
Fuel Required Adjustments (1000 KG)
AIR DISTANCE (NM)
GROUND
DISTANCE
(NM)
AIR DISTANCE (NM)
HEADWIND COMPONENT (KTS) TAILWIND COMPONENT (KTS)
100 80 60 40 20 20 40 60 80 100
286 264 244 227 213 200 190 181 173 166 159
579 533 492 457 427 400 380 362 346 331 318
874 803 740 686 641 600 571 544 519 497 477
1171 1074 989 917 855 800 761 725 692 662 635
1470 1347 1238 1147 1069 1000 951 906 864 827 793
1771 1621 1489 1379 1284 1200 1141 1086 1037 992 951
2075 1898 1742 1611 1500 1400 1331 1267 1209 1156 1109
2382 2176 1995 1844 1715 1600 1521 1448 1381 1321 1267
2691 2456 2250 2077 1931 1800 1711 1628 1553 1485 1424
AIR
DIST
(NM)
PRESSURE ALTITUDE (1000 FT)
10 16 20 24 28
FUEL
(1000 KG)
TIME
(HR:MIN)
FUEL
(1000 KG)
TIME
(HR:MIN)
FUEL
(1000 KG)
TIME
(HR:MIN)
FUEL
(1000 KG)
TIME
(HR:MIN)
FUEL
(1000 KG)
TIME
(HR:MIN)
200 1.5 0:40 1.2 0:38 1.1 0:37 1.0 0:37 0.9 0:36
400 3.0 1:18 2.6 1:13 2.4 1:11 2.2 1:09 2.1 1:07
600 4.5 1:57 3.9 1:49 3.6 1:44 3.4 1:41 3.3 1:39
800 5.9 2:36 5.3 2:24 4.9 2:18 4.6 2:13 4.5 2:10
1000 7.4 3:16 6.6 3:00 6.1 2:53 5.7 2:46 5.6 2:42
1200 8.8 3:56 7.9 3:37 7.3 3:27 6.9 3:19 6.7 3:14
1400 10.2 4:37 9.1 4:14 8.5 4:02 8.0 3:53 7.8 3:46
1600 11.6 5:19 10.4 4:52 9.6 4:37 9.1 4:26 8.8 4:18
1800 13.0 6:02 11.6 5:30 10.8 5:13 10.2 5:00 9.8 4:51
REFERENCE FUEL REQUIRED
(1000 KG)
WEIGHT AT CHECK POINT (1000 KG)
35 45 50 55 65
5 -0.7 -0.2 0.0 0.4 1.3
10 -1.4 -0.5 0.0 0.9 2.6
15 -2.1 -0.7 0.0 1.3 3.9
June 08, 2001
