Boeing 737 - Page 172

737 Operations Manual
Performance Inflight -
General
737-500/CFM56-3_20K
Copyright © The Boeing Company. See title page for details.
PI.30.14 D6-27370-400E-TBCE
ADVISORY INFORMATION
Slush/Standing Water Takeoff (18.5K Derate)
Weight Adjustment (1000 KG)
V1(MCG) Limit Weight (1000 KG)
V1 Adjustment (KIAS)
18.5K DERATE
FIELD/OBSTACLE
LIMIT WEIGHT
(1000 KG)
SLUSH/STANDING WATER DEPTH
3mm (0.12 INCHES) 6mm (0.25 INCHES) 13mm (0.50 INCHES)
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
68 -7.7 -8.0 -8.4 -9.6 -10.0 -10.4 -13.1 -10.5 -12.3
64 -7.4 -7.9 -8.4 -9.1 -9.9 -10.5 -12.6 -12.2 -12.7
60 -6.8 -7.5 -8.1 -8.3 -9.3 -10.1 -11.6 -12.4 -12.6
56 -6.1 -6.8 -7.6 -7.3 -8.4 -9.4 -10.2 -11.6 -12.1
52 -5.4 -6.1 -6.9 -6.4 -7.4 -8.5 -8.8 -10.2 -11.2
48 -4.8 -5.3 -6.0 -5.5 -6.3 -7.5 -7.5 -8.7 -10.1
44 -4.2 -4.6 -5.2 -4.8 -5.4 -6.3 -6.5 -7.4 -8.8
40 -3.8 -3.9 -4.4 -4.4 -4.7 -5.3 -6.3 -6.8 -7.5
36 -3.6 -3.6 -3.7 -4.2 -4.3 -4.3 -6.8 -7.3 -6.1
ADJUSTED
FIELD
LENGTH
(FT)
SLUSH/STANDING WATER DEPTH
3mm (0.12 INCHES) 6mm (0.25 INCHES) 13mm (0.50 INCHES)
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
4200 31.2
4600 31.2 33.5 38.0 30.4
5000 38.3 28.9 40.6 31.8 44.7 35.9 30.2
5400 45.4 34.9 47.8 37.7 30.8 51.2 41.5 35.1
5800 52.8 40.8 33.3 55.4 43.6 36.0 57.6 47.1 40.1
6200 60.6 46.8 38.6 63.2 49.5 41.3 64.1 52.9 45.0
6600 68.5 53.0 43.9 70.9 55.8 46.6 70.6 58.8 49.9
7000 59.6 49.2 62.1 51.9 64.6 54.7
7400 66.1 54.7 68.4 57.2 70.4 59.6
7800 72.7 60.3 74.7 62.5 64.5
8200 65.9 67.8 69.4
8600 71.6 73.1 74.2
1. Enter Weight Adjustment table with slush/standing water depth and 18.5K derate dry field/obstacle
limit weight to obtain slush/standing water weight adjustment.
2. Adjust field length available by -99ft/+99ft for every 5°C above/below 4°C
3. Find V1(MCG) limit weight for temperature adjusted field length and pressure altitude.
4. Max allowable slush/standing water limited weight is lesser of weights from 1 and 3.
WEIGHT
(1000 KG)
SLUSH/STANDING WATER DEPTH
3mm (0.12 INCHES) 6mm (0.25 INCHES) 13mm (0.50 INCHES)
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
68 -7 -6 -4 0 -1 -2 -4 -2 3
64 -9 -8 -6 -2 -2 -3 -2 -1 2
60 -11 -10 -8 -5 -3 -3 1 0 0
56 -14 -12 -9 -7 -5 -3 1 1 -1
52 -16 -14 -11 -10 -8 -5 0 0 0
48 -18 -16 -13 -13 -10 -6 -3 -1 0
44 -19 -18 -15 -16 -13 -8 -6 -2 0
40 -20 -19 -16 -18 -15 -10 -9 -4 0
36 -21 -20 -18 -18 -17 -13 -11 -7 -2
1. Obtain V1, VR and V2 for the actual weight.
2. If V1(MCG) limited, set V1 = V1(MCG). If not V1(MCG) limited, enter V1 Adjustment Table with the
actual weight to obtain V1 speed adjustment. If adjusted V1 is less than V1(MCG), set V1 = V1(MCG).
December 07, 2001
