737 Operations Manual
Performance Inflight -
General
737-500/CFM56-3_20K
Copyright © The Boeing Company. See title page for details.
PI.30.22 D6-27370-400E-TBCE
Flight With Unreliable Airspeed/Turbulent Air Penetration
Altitude and/or vertical speed indications may also be unreliable.
Terminal Area
%N1 for Level Flight
Final Approach
Gear Down, %N1 for 3° Glideslope
FLAP POSITION (SPEED)
WEIGHT (1000 KG)
32 36 41 45 50
FLAPS UP (GEAR UP) PITCH ATT 3.7 4.4 5.0 5.7 6.4
(210 KIAS) %N1 53 54 56 58 60
FLAPS 1 (GEAR UP) PITCH ATT 3.9 4.7 5.4 6.2 7.0
(190 KIAS) %N1 55 57 58 60 62
FLAPS 5 (GEAR UP) PITCH ATT 3.9 4.8 5.8 6.7 7.6
(170 KIAS) %N1 53 56 58 61 63
FLAPS 15 (GEAR DOWN) PITCH ATT 3.8 4.9 5.9 7.0 8.1
(150 KIAS) %N1 55 58 61 64 67
FLAP POSITION
WEIGHT (1000 KG)
32 36 41 45 50 54
FLAPS 40
PITCH ATT 0.7 0.8 0.9 0.9 1.0 1.1
%N1 495356586163
KIAS 111 115 125 132 138 144
FLAPS 30
PITCH ATT 2.4 2.4 2.5 2.5 2.5 2.6
%N1 434649525457
KIAS 114 121 129 135 142 148
FLAPS 15
PITCH ATT 4.9 4.9 5.0 5.0 5.0 5.0
%N1 394244464951
KIAS 120 128 136 143 150 157
June 07, 2002
