Boeing 737 - Page 192

737 Operations Manual
Performance Inflight -
Advisory Information
737-500/CFM56-3_20K
Copyright © The Boeing Company. See title page for details.
PI.32.6 D6-27370-400E-TBCE
ADVISORY INFORMATION
Advi sory In formati on
Brake Cooling Schedule
Reference Brake Energy Per Brake (Millions of Foot Pounds)
Adjusted Brake Energy Per Brake (Millions of Foot Pounds)
No Reverse Thrust
Adjusted Brake Energy Per Brake (Millions of Foot Pounds)
Two Engine Detent Reverse Thrust
WIND CORRECTED BRAKES ON SPEED (KIAS)*
60 80 100 120 140
WEIGHT
(1000 KG)
OAT
(°C)
PRESS ALT PRESS ALT PRESS ALT PRESS ALT PRESS ALT
024024024024024
65
-20 7.0 7.5 8.1 11.3 12.2 13.1 16.2 17.7 19.1 21.9 24.1 25.9
0 7.5 8.2 8.9 12.3 13.2 14.3 17.7 19.3 20.8 23.9 26.0 27.9
20 8.1 8.8 9.6 13.3 14.3 15.4 19.2 20.8 22.4 25.9 28.3 30.0
40 8.7 9.5 10.2 14.3 15.3 16.6 20.7 22.4 24.1 27.9 30.7 32.1
60
-20 6.6 7.2 7.7 10.6 11.5 12.4 15.3 16.6 18.0 20.5 22.2 24.0 26.5
0 7.1 7.8 8.4 11.5 12.5 13.5 16.7 18.1 19.6 22.4 24.3 26.1 28.9
20 7.7 8.4 9.1 12.5 13.5 14.5 18.1 19.7 21.2 24.3 26.3 28.3 31.3
40 8.2 9.1 9.7 13.4 14.5 15.6 19.5 21.2 22.8 26.2 28.3 30.4 33.4
55
-20 6.1 6.6 7.1 9.8 10.6 11.5 14.1 15.3 16.5 19.1 20.5 22.1 24.5 26.4
0 6.6 7.2 7.7 10.7 11.6 12.5 15.4 16.7 18.0 20.7 22.4 24.1 26.7 28.8
20 7.2 7.7 8.3 11.6 12.5 13.5 16.6 18.1 19.5 22.4 24.3 26.1 28.9 31.2
40 7.7 8.3 8.9 12.5 13.5 14.5 17.9 19.5 21.0 24.1 26.2 28.2 31.1 33.6
50
-20 5.7 6.2 6.7 9.1 9.8 10.6 13.2 14.3 15.3 17.6 19.0 20.4 22.6 24.5 26.4
0 6.2 6.7 7.3 9.9 10.7 11.6 14.4 15.6 16.7 19.2 20.7 22.2 24.7 26.7 28.8
20 6.7 7.3 7.9 10.6 11.6 12.5 15.5 16.8 18.2 20.7 22.4 24.1 26.7 28.9 31.2
40 7.2 7.8 8.4 11.5 12.5 13.5 16.7 18.1 19.6 22.3 24.1 26.0 28.8 31.1 33.5
45
-20 5.5 6.0 6.3 8.5 9.2 9.9 12.2 13.1 14.1 16.0 17.4 18.8 20.5 22.2 24.0
0 5.9 6.4 6.9 9.3 10.0 10.8 13.2 14.3 15.3 17.4 18.9 20.4 22.4 24.3 26.2
20 6.4 6.9 7.4 10.1 10.9 11.7 14.3 15.4 16.6 18.9 20.5 22.1 24.3 26.3 28.3
40 6.8 7.4 7.9 10.8 11.7 12.6 15.3 16.5 17.8 20.4 22.0 23.8 26.2 28.3 30.5
40
-20 5.1 5.5 5.9 7.9 8.5 9.1 11.0 12.0 12.9 14.6 15.8 17.2 18.8 20.2 21.7
0 5.5 5.9 6.4 8.6 9.3 10.0 12.0 13.0 14.0 15.9 17.3 18.7 20.5 22.1 23.8
20 5.9 6.4 6.9 9.2 10.0 10.8 13.0 14.1 15.2 17.3 18.8 20.2 22.1 24.0 25.8
40 6.3 6.8 7.4 9.9 10.8 11.6 14.0 15.1 16.3 18.6 20.2 21.7 23.8 25.8 27.8
* To correct for wind, enter table with the brakes on speed minus one half the headwind or plus 1.5 times the
tailwind.
If ground speed is used for brakes on speed, ignore wind and enter table with sea level, 15°C.
REFERENCE BRAKE ENERGY PER BRAKE (MILLIONS OF FOOT POUNDS)
EVENT 5 10 15 20 25 30 35
RTO MAX MAN 5 10 15 20 25 30 35
LANDING
MAX MAN 3.4 7.4 11.9 16.5 21.1 25.8 30.5
MAX AUTO 3.2 7.0 11.4 15.5 19.7 24.2 28.5
AUTOBRAKE 3 3.1 6.7 10.8 14.6 18.2 22.2 25.9
AUTOBRAKE 2 2.9 6.3 10.3 13.8 17.0 20.1 23.2
AUTOBRAKE 1 2.9 6.2 10.0 13.4 16.5 19.7 22.6
REFERENCE BRAKE ENERGY PER BRAKE (MILLIONS OF FOOT POUNDS)
EVENT 5 10 15 20 25 30 35
LANDING
MAX AUTO
AUTOBRAKE 3
AUTOBRAKE 1 & 2
2.6
1.9
1.9
5.6
3.9
3.7
8.9
6.1
5.8
12.4
8.4
7.8
16.0
10.5
9.6
19.4
12.6
11.3
22.8
14.7
12.8
June 07, 2002
