Boeing 737 - Page 67

737 Operations Manual
Performance Inflight -
Engine Inoperative
737-300/CFM56-3_22K
Copyright © The Boeing Company. See title page for details.
D6-27370-400E-TBCE PI.13.9
ENGINE INOP
MAX CONTINUOUS THRUST
Long Range Cruise Diversion Fuel and Time
Ground to Air Miles Conversion
Reference Fuel and Time Required at Check Point
Fuel Required Adjustment (1000 KG)
AIR DISTANCE (NM)
GROUND
DISTANCE
(NM)
AIR DISTANCE (NM)
HEADWIND COMPONENT (KTS) TAILWIND COMPONENT (KTS)
100 80 60 40 20 20 40 60 80 100
299 272 249 230 214 200 190 181 173 166 159
608 552 504 464 430 400 380 362 345 330 316
920 834 759 697 646 600 570 542 517 494 473
1235 1118 1015 932 862 800 760 722 688 658 630
1553 1403 1273 1167 1078 1000 949 903 860 821 787
1873 1691 1532 1403 1295 1200 1139 1082 1031 984 943
2196 1980 1792 1640 1512 1400 1328 1262 1202 1147 1099
2524 2273 2055 1877 1730 1600 1517 1441 1372 1310 1255
AIR
DIST
(NM)
PRESSURE ALTITUDE (1000 FT)
10 14 18 22 26
FUEL
(1000 KG)
TIME
(HR:MIN)
FUEL
(1000 KG)
TIME
(HR:MIN)
FUEL
(1000 KG)
TIME
(HR:MIN)
FUEL
(1000 KG)
TIME
(HR:MIN)
FUEL
(1000 KG)
TIME
(HR:MIN)
200 1.4 0:42 1.2 0:40 1.1 0:39 1.0 0:38 0.9 0:37
400 2.8 1:22 2.6 1:18 2.3 1:14 2.1 1:11 2.0 1:09
600 4.2 2:03 3.9 1:56 3.5 1:50 3.3 1:46 3.1 1:42
800 5.6 2:44 5.2 2:35 4.7 2:26 4.4 2:20 4.1 2:15
1000 7.0 3:26 6.4 3:14 5.9 3:03 5.5 2:55 5.2 2:48
1200 8.3 4:08 7.7 3:54 7.1 3:40 6.6 3:30 6.2 3:22
1400 9.6 4:51 8.9 4:34 8.2 4:18 7.7 4:05 7.2 3:56
1600 11.0 5:35 10.1 5:15 9.4 4:57 8.7 4:41 8.2 4:30
REFERENCE FUEL REQUIRED
(1000 KG)
WEIGHT AT CHECK POINT (1000 KG)
35 40 45 50 55 60
2 -0.2 -0.1 0.0 0.1 0.3 0.5
4 -0.3 -0.2 0.0 0.3 0.7 1.0
6 -0.5 -0.3 0.0 0.5 1.0 1.5
8 -0.7 -0.4 0.0 0.6 1.3 2.0
10 -0.9 -0.4 0.0 0.7 1.6 2.5
12 -1.0 -0.5 0.0 0.9 1.8 2.9
14 -1.2 -0.6 0.0 1.0 2.1 3.3
June 08, 2001
