74 - S5IND
Signal on digital input S5IND (X210A.7) or re-
mote operation via communication interface.
75 - S6IND
Signal on digital input S6IND (X210B.1) or re-
mote operation via communication interface.
76 - MFI1D
Signal at multifunction input MFI1 (X210B.6) in
Operation Mode 452 = 3 - digital input or re-
mote operation via communication interface.
157 - Warning Mask
The defined warning mask of parameter Create
Warning Mask 536 signals a critical operating
158 - Timer 1
Output signal of the time function according to
the input connection Timer 1 83.
159 - Timer 2
Output signal of the time function according to
the input connection Timer 2 84.
160 - Ready Signal
Frequency inverter is initialized and ready for
operation.
161 - Run Signal
Signal enable STO (S1IND/STOA and
S7IND/STOB) and a start command are present,
output frequency available.
Monitoring function signals an operational fault.
163 -
Reference Frequency
reached
Signal when the Actual frequency 241 has
reached the reference frequency.
164 - Setting Frequency
Signal when the actual value Stator Frequency
210 exceeds the value of Setting Frequen-
510.
165 - Warning Ixt
The monitoring functions report an overload of
the frequency inverter.
166 -
Warning Heat Sink Tem-
perature
Max. heat sink temperature T
K
of 80 °C less the
Warning Limit Heat Sink Temp. 407 reached.
167 -
Warning Inside Tempera-
ture
Max. inside temperature T
i
of 65 °C less the
Warning Limit Inside Temp 408 reached.
168 -
Warning Motor Tempera-
ture
Warning behavior according to parameterized
Motor Temp. Operation mode 570 at max. motor
169 - General Warning
Signal when Warnings 269 are displayed with a
critical operating point.
170 - Warning Overtemperature
− “80 °C minus Warning Limit Heat Sink
Temp.
407” or
− “65 °C minus
Warning Limit Inside
Temp.
408”
171 - Output Comparator 1
The comparison according to the selected Op-
eration mode Comparator 1 540 is true.
172 -
Negated Output Compara-
tor 1
Operation mode 171 with inverted logic (LOW
active)
173 - Output Comparator 2
The comparison according to the selected Op-
eration mode Comparator 2 543 is true.
174 -
Negated Output Compara-
tor 2
Operation mode 173 with inverted logic (LOW
active).
175 - Digital Signal 1
Signal according to parameter Operation mode
digital output 1 530.
176 - Digital Signal 2
Signal according to parameter Digital Opera-
tion 554 on multifunctional output MFO1.
177 - Digital Signal 3
Signal according to parameter Operation mode
digital output 3 532.
178 -
Reference Percentage
reached
Signal when the Actual percentage 230 has
reached the reference percentage 229.
