Ups general description & installation
Rev.D JSE410920 22/07/08 JUD408311
9 of 31
2.2.6 Front panel
The front panel of the UPS, consisting of a four row alphanumeric displays plus 5
function keys, allows the complete monitoring of the UPS status.
The mimic diagram helps to understand the operating status of the UPS.
For more information see the chapter “FRONT PANEL”.
