4) After the connection re-insert the battery trays as shown in pictures 14.
Picture 14 – 3,3Ah battery connected
Put back and fix the front cover with the four screws.
WARNING
After the battery installation, before closing BCB, check the voltage polarity in the top
and bottom of the BCB circuit breaker.
