Borri B8031 - Picture 17 - 7 Ah;9 Ah Battery Connected

Ups general description & installation
24 of 31
JUD408311 Rev.D JSE410920 22/07
/
08
4) After the connection re-insert the battery trays as shown in picture 17.
Picture 17 – 7Ah/9Ah battery connected
Put back and fix the front cover with the four screws.
