Maintenance and Replacement
8–2
1070 073 822-104 (02.06) GB
8.1 Fuse protection
The IPC and IPC300 are equipped with a replaceable power supply fuse:
D 6.3 A (5x20), medium time-lag for 24 VDC power supply
D 1.25 A (5x20), medium time-lag for 230 VAC power
D IPC: accessible after removal of the CD-ROM drive.
(refer to procedures in Section 8.2.1)
D IPC300: accessible externally at the front panel.
Refer to fuse ordering information in Section 10.3.
. In the event that the power supply remains faulty after replacing the
power supply fuse, please contact Bosch Rexroth Service:
Telephone: (+49) (0 60 62) 78-888.
CAUTION
Loss of data!
Service repairs of devices returned by customers do not entail back-
ups of user data. Repaired units are returned with formatted hard
disk and newly installed software.
IPC
deinstalled
CD-ROM drive
Mother board
Fuse
