Interfaces, Ports & Connectors
6–8
1070 073 822-104 (02.06) GB
6.2.2 COM1 through COM4 settings
Control Panel
For information about setting the communication parameters for serial inter-
faces, refer to the manual supplied with the installed operating system.
Windows 95/NT: Go to Start / Settings / Control Panel, etc.
BIOS
The factory-shipped BIOS settings for COM1 through COM4 have been set
to Present.
CAUTION
Interrupt (IRQ) and I/O address must correspond to BIOS settings.
In the case of address conflicts regarding COM3/4, e.g., if IRQ 10 or
11 are already in use by other PC expansion cards, free IRQs must be
used instead.
