6 Interfaces, Ports & Connectors
6.1 Overview
The following table specifies the installed IPC connector types, as well as
their mating connectors.
Label
on housing
Interface service Physical
connector
Mating connector
or cable
IPC IPC300
COM1 Serial port:
RS-232,
IPC: free assignment
IPC300:
alternative, X57
Male DB-9
connector
Female DB-9 connector
COM2 Serial port:
RS-232 for touch screen.
Without touch screen:
IPC: alternative to X57
IPC300: free assignment
Male DB-9
connector
Female DB-9 connector
X57 Serial port:
RS-485/422:
IPC: alternative, COM2
IPC300: alternative to
COM1
Male DB-9
connector
Female DB-9 connector
COM3 Serial port:
RS-232, free assignment
Male DB-9
connector
Female DB-9 connector
COM4 – Serial port:
RS-232 for UPS logic
Male DB-9
connector
Female DB-9 connector
LPT1 Parallel port:
Supports SPP, EPP,
ECO mode
Female DB-25
connector
Male DB-25 connector
(e.g., printer cable)
Ethernet Ethernet 10 Base T
Network connection
Female RJ45,
8-pin
Male RJ45 connector,
8-conductor, twisted prs.
USB USB interface Female USB
connector, 4-pin
Male USB, 4-conductor
LVDS – for BF2xxT:
Video transmission
Female RJ45,
8-pin
Male RJ45 connector,
8-conductor, twisted prs.
– LCD Gigabit for BF3xxT:
Video transmission and
RS-422 for touch screen
controller (COM2)
Female RJ45,
8-pin
Male RJ45 connector,
8-conductor, twisted
prs., CAT7
VGA VGA connection for
external CRT monitor
Female VGA HD
connector, 15-pin
Monitor cable w/ male
VGA HD connect.,15-pin
X11 BF2xxT, BF3xxT:
Power supply, mouse &
keyboard
Female DB-15
connector
Male DB-15 connctor
Keyb PS/2 mini DIN keyboard Female PS/2
mini DIN, 6-pin
Keyboard cable w/ male
PS/2 mini DIN, 6-pin
Mouse PS/2 mini DIN mouse Female PS/2
mini DIN, 6-pin
Male PS/2 mini DIN,
6-pin
As described in Section 5.3:
X20 PC power supply:
230/115 VAC,
alternative to X10_1
Non-heating
appliance
connector, male
Power cord w/ female
non-heating appliance
connector
X10_1 PC power supply:
24 VDC, alternative to
X20
Male Weidmüller
push-lock ter-
minal, MSTB 1.5,
4-pin
Female Weidmüller
push-lock terminal,
MSTB 1.5, 4-pin
