Bosch Rexroth IPC - 230;115 VAC Connection Diagrams

Electrical Connections
5–10
1070 073 822-104 (02.06) GB
0.5 mm
2
, up to 4 m
0.75 mm
2
, up to 6 m
1.5 mm
2
, up to 10 m
Distances in excess of
10 m necessitate a separate
power supply at the machine!
(*)
24 VDC
230 VAC
(see previous page)
Cross-sections dependent
on current draw, but MIN
of 0.5
mm
2
(*)
Cross-sections dependent
on current draw, but MIN
of 0.75
mm
2
BF2xxT
Control Panel
X33
LVDS
X34
PE
PE
IPC
(230/115 VAC version)
Power supply (protective
separation to EN 60950)
X11
LVDS
COM2
BF3xxT
Control Panel
X33
LCD
X10_1
PE
PE
IPC300
(230/115 VAC version)
Power supply (protective
separation to EN 60950)
X11
LCD
X10_2
Fan power
Fan
U2
N1
PE
X20
U2
N1
PE
X20
