Bosch Access Modular Controller 2 Installation Manual

16 en | Installing Access Modular Controller 2
2021-04 | V04 | IM
Installation manual
Bosch Security Systems B.V.
4.3 Opening the case
i
Notice!
To open the controller, first remove all pluggable connectors.
The controller’s case consists of a top cover mounted with a two-point snap-in closure on a
chassis. To open the case, push down the two snap-ins with a screwdriver, then swing the
cover down.
Figure4.3: Opening the controller´s case
