3 Introduction
3.1 Description
The controller is equipped with four independent interfaces for Wiegand type readers. It is
able to control two doors with one reader in each direction and up to four doors with a reader
in one direction only.
Figure3.1: Access Modular Controller
All necessary information for access verification is stored in a battery buffered on-board
memory and a Compact Flash (CF) memory card. This guarantees autonomous access
decisions and complete access registrations even if the management host system is offline.
The built in compact flash adapter provides adequate storage capability for cardholders and
events.
The electronics of the controller are completely covered by a plastic housing. The LCD (liquid
crystal display) provides all important status information.
Unsecured Area
Secured Area
Figure3.2: Example
