Bosch Access Modular Controller 2 Installation Manual

44 en | Technical specifications Access Modular Controller 2
2021-04 | V04 | IM
Installation manual
Bosch Security Systems B.V.
10 Technical specifications
Mechanical
Type DIN rail mounting
Housing material ABS and Polycarbonate (UL94V-0)
Dimensions (H × W × D) 232 mm × 90 mm × 63 mm
(9.13 in. × 3.54 in. × 2.48 in.)
Weight 681 g
Color White
System specifications
Memory – Serial EEPROM
– Pluggable 2 GB compact flash
Reader interfaces – 4× Wiegand
Power 280 mA each 11.8 VDC to 12 VDC
Host interface – Ethernet 10/100 MBit/s
– RS485
– AES128 encrypted
Extension interface – RS485 9,6 kBit/s, no parity, 8 bit, 2 stop
bit
Outputs – 8× relay outputs
– 30 V DC max. (switching voltage)
– 1,25 A max. (switching current) @ 30Vdc
– Operation mode: wet and dry
Inputs 8 analog inputs with tamper detection
Power consumption 5 VA
Tamper 2-wire input for external tamper contact
Reset button Yes
Power – 10 VDC to 30 VDC
– 60 VA max.
– 55 VA (available for external devices)
Display LCD
Environmental
Temperature 0 °C to +50 °C (32 °F to 122 °F)
Environmental rating IP 30
RoHS Compliant
