Bosch Access Modular Controller 2 Installation Manual

Access Modular Controller 2 Installing | en 31
Bosch Security Systems B.V.
Installation manual
2021-04 | V04 | IM
To detect the four states, the voltage drop in the connecting cable may not exceed special
values. The following table shows the maximum values of permissible cable resistance
depending on the used resistor combination.
R
p
1k 1k2 1k5 1k8 2k2 2k7 3k3 3k9 4k7 5k6 6k8 8k2
R
s
1k 220 220 220 210 200
1k2 260 270 270 270 260 240
1k5 310 330 340 350 350 340 310 280
1k8 340 380 390 410 410 410 400 370 330 290 200
2k2 430 460 490 510 520 510 500 460 420 340 240
2k7 490 540 570 620 630 640 640 620 580 510 420
3k3 610 650 700 740 770 780 770 750 700 620
3k9 720 790 850 890 910 910 910 880 810
4k7 880 960 960 970 1100 1100 1050 1050
5k6 1050 1100 1200 1200 1300 1300 1250
6k8 1300 1400 1500 1500 1500 1500
8k2 1500 1650 1700 1800 1900
Tab.4.3: Maximum values of cable resistance per used resistor combination in Ohm
