Access Controller AMC-4W Description of the AMC-4W
Bosch Security Systems | V.3.1/2006-09 Installation Guide 11
3. Description of the AMC-4W
The AMC-4W is equipped with four independent interfaces for Wiegand type
readers. By that it is able to control two doors with a reader in each direction
and up to four doors with a reader in one direction only.
Figure 1: The Access Controller AMC-4W
All necessary information for access verification is stored in a battery buffered
on-board memory and a Compact Flash (CF) memory card. This guarantees
autonomous access decisions and complete access registrations even if the
management host system is offline. The built in compact flash adapter provides
adequate storage capability for cardholders and events, simply by exchanging
the standard compact flash card with 64 MB by one with 128 MB, 256 MB,
512 MB or 1 GB capacity.
