Bosch AMC-4W User Manual

Access Controller AMC-4W Operating the AMC-4W
Bosch Security Systems | V.3.1/2006-09 Installation Guide 41
6. Operating the AMC-4W
6.1. Status Display of the AMC-4W
The LC Display delivers information about the AMC-4W status. Push the
'Dialog' button as shown in figure 30 to switch between different modes.
Figure 30: Location of the ‘Dialog’ button
The display mode which has been set remains until the next operation of the
‘Dialog’ button.
Push Display: Description:
0
V00.35 02.05.05
Software version of the downloader
1
99999876543210 A
Bosch serial number and bus address
A = address 1
B = address 2
C = address 3
D = address 4
E = address 5
F = address 6
G = address 7
H = address 8

Bosch AMC-4W Specifications

General

Brand	Bosch
Model	AMC-4W
Category	Controller
Language	English
