RE 92050-01-X-B2/2019-08-23, BoschRexrothAG
35 Axial piston variable pump | A4VSO Series 10, 11 and 30
Dimensions, through drive
Flange ISO 3019-2 (metric) Hub forsplined shaft
2)
Code
Diameter Symbol Diameter 40 71 125 180 250 355 500
315-8
N80×3×25×8H
– – – – – –
●
K43
● = Available ○ = On request ‒ = Not available
▼ 315-8
22º30´
8×45º
(=360º)
N
M
ø315
+0.10
+0.03
1)
45º
A7
A4
A3
A2
ø360
A1 (to mounting flange)
Section M-N
K43 NG A1 A2 A3 A4 A7
3)
500 590 53.5 71.9 19 M20; 26 deep
Notice
All attachment pumps must match the ATEX classification
for the application in question.
1) Mounting bolts and O-ring seal are included in the scope of
delivery
2) Splined hub according to DIN 5480
3) Thread according to DIN 13, see Part I for maximum tightening
torques.
