Bosch rexroth A4VSO 10 Series User Manual

BoschRexrothAG, RE 92050-01-X-B2/2019-08-23
36 A4VSO Series 10, 11 and 30 | Axial piston variable pump
Dimensions, through drive
Dimensions [mm]
Flange ISO3019-2 (metric) Hub forsplined shaft
2)
Code
Diameter Symbol Diameter 40 71 125 180 250 355 500
80-2
3/4in 11T 16/32DP ○ ●
– – – –
○
KB2
, , ,
3/4in 11T 16/32DP
– –
● ● ● ●
– UB2
● = Available ○ = On request ‒ = Not available
▼ 80-2 ▼ 80-2
N
M
ø80
+0.05
+0.02
1)
45º
A5
A4
A3
A2
A8
A7
ø109
A1 (to mounting flange)
Section M-N
A1 (to mounting flange)
Section M-N
N
M
ø80
+0.05
+0.02
1)
45º
A4
A3
A2
A8
A7
ø109
KB2 NG A1 A2 A3 A4 A5 A7 A8
3)
UB2 NG A1 A2 A3 A4 A7
3)
A8
3)
71 291 21.5 19 10 2 140 M10; 15 deep 125 367 40.5 19.4 9 180 M10; 16 deep
180 393 40.5 19.4 9 180 M10; 16 deep
250 453 40.5 19 9 200 M10; 16 deep
355 482 40.4 19 9 200 M10; 16 deep
Notice
All attachment pumps must match the ATEX classification
for the application in question.
1) Mounting bolts and O-ring seal are included in the scope of
delivery
2) Involute spline according toANSIB92.1a, 30° pressure angle,
flatroot, side fit, tolerance class5
3) Thread according to DIN 13, see Part I for maximum tightening
torques.
