10-2 Ordering Information IndraControl L40
DOK-CONTRL-IC*L40*****-PR02-EN-P
10.2 Order Data
Control
Ordering designation Part number Description
CLM40.1-SP-220-NA-NNNN-NW 1070170260 IndraControl L40 with SERCOS and PROFIBUS interface
CLM40.1-NP-220-NA-NNNN-NW 1070170261 IndraControl L40 with PROFIBUS interface
Necessary Accessories (Connector Set)
The following connector set is required for connecting the
IndraControl L40:
Ordering designation Part number Description
R-IB IL CML S01-PLSET R911299856 Connector set for IndraControl L40
Additional Accessories (Blower and Rexroth Inline Modules)
Blower
Ordering designation Part number Description
CAL01.1-F1 R911306144 Blower
Rexroth Inline Modules
Ordering designation Part number Description
Digital input terminals:
R-IB IL 24 DI 2 R911289286
2 inputs, 24 V DC, 4-wire connection, width 12.2 mm
R-IB IL 24 EDI 2-DES R911289292 2 Desina diagnostic inputs, overall width 12.2 mm
R-IB IL 24 DI 4 R911289287 4 inputs, 24 V DC, 3-wire connection, width 12.2 mm
R-IB IL 24 DI 8 R911289288 8 inputs, 24 V DC, 4-wire connection, width 48.8 mm
R-IB IL 24 DI 16 R911289290 16 inputs, 24 V DC, 3-wire connection, width 48.8 mm
R-IB IL 24 DI 32/HD R911297188 32 inputs, 24 V DC, 1-wire connection, width 48.8 mm
Digital output terminals:
R-IB IL 24/230 DOR1/W R911289301 1 alternating relay contact, 5 – 253 V AC, 3 A, gold-plated,
for switching of lamp loads, width 12.2 mm
R-IB IL 24 DO 2-2A R911289294 2 outputs, 24 V DC, 2 A, 4-wire connection,
width 12.2 mm
R-IB IL 24 DO 4 R911289295 4 outputs, 24 V DC, 500 mA, 3-wire connection, overall
width 48.8 mm
R-IB IL 24/230 DOR4/W R911289302 4 alternating relay contacts, 5 – 253 V AC, 3 A, gold-plated,
overall width 48.8 mm
R-IB IL 24 DO 8 R911289297 8 outputs, 24 V DC, 500 mA, 4-wire connection, overall
width 48.8 mm
R-IB IL 24 DO 8-2A R911289298 8 outputs, 24 V DC, 2 A, 4-wire connection, overall width
48.8 mm
R-IB IL 24 DO 16 R911289299 16 outputs, 24 V DC, 500 mA, 3-wire connection, overall
width 48.8 mm
