Any zone that registers one active pulse automatically increments any other zone pulse count
that already registered at least one activate pulse during its respective time. To enable this
feature, select Option 4 in Location 494 (refer to System Options 3, page 139).
Notice!
24-Hour Zones cannot receive any handover pulses from other zones. 24-Hour Zones can
handover pulses to other zones.
Zone Pulse Count Time
Zone pulse count time is the time frame or period over which the programmed number of
pulses must register to activate an alarm.
20 ms Option Loop Response Time
(sec)
150 ms Option Loop Response Time
(sec)
0 0.5 8 20
1 1 9 30
2 2 10 40
3 3 11 50
4 4 12 60
5 5 13 90
6 10 14 120
7 15 15 200
Table 13.1: Zone Pulse Count Times
For zone pulse count time, options 0 to 7 have a zone loop response time of 20 ms and
options 8 to 15 have a zone loop response time of 150 ms. Loop response time is the length of
time a zone must be unsealed before it can register as a valid pulse.
Inertia sensors should use options 0 to 7 and PIR detectors should use options 8 to 15.
Zone Options 1
This location has four programming options. You can select any combination of the options by
programming a single value. Calculate this value by adding the option bit numbers together.
Option Description
1 Lockout Siren/Lockout Report
2 Delay Alarm reporting
4 Silent Alarm
8 Sensor Watch
1 – Lockout Siren and Lockout Report
Lockout refers to certain activations per arming cycle (that is, a zone programmed for Lockout
can activate the sirens or communication module for certain times as programmed).
13.3.4
13.3.5
100 en | Zone Information Control Panel
2017.10 | 03 | F.01U.298.026 Installation Guide Bosch Security Systems, Inc.
