Partitioning
The Control Panel includes the partitioning feature, which can effectively transform your single
control panel into two separate areas. Normally, arming and disarming the system turns the
entire system on or off. When Control Panel is partitioned, you can arm or disarm an individual
area without affecting the other area. Partitioning is extremely useful when you want to secure
sheds, dual occupancy dwellings, accessory dwellings, shops, and offices.
Programming
Locations 500 and 501 apply only to a partitioned Control Panel.
These locations have up to four options. You can select any combination of these options by
programming a single value. Calculate this value by adding the option bit numbers together.
Partitioning Options 1
Item Location Option Default New
Partitioning Options 1 0500 1 = First to Disarm/Last to Arm reporting
2 = Reserved
4 = Reset sirens from any area allowed
8 = Reserved
0
1 – First To Disarm/Last To Arm Reporting
Select this option if only one Arm/Disarm Report is required for a partitioned system. Instead
of sending individual Arm/Disarm reports for each area, an Arm Report is sent only after both
areas are armed and a Disarm Report is sent as soon as one area is disarmed.
The reports are sent with the User Codes allocated to the specific area. You must allocate the
user codes to the specific area and program user codes to have a priority level set with no
arm/disarm reports.
Notice!
This option is applicable only when all User Codes have a priority level set with no arm/
disarm reports. If User Codes have priority levels set to Arm/Disarm Reports, an Arm/Disarm
report is always sent when any area is disarmed or armed, regardless of whether the area was
first to disarm or last to arm.
4 – Reset Sirens from Any Area Allowed
This option applies only to a partitioned control panel. If this option is selected, any valid User
Code from Area 1 or Area 2 can reset the horn speaker, strobe, or bell outputs while in alarm.
This option does not allow a User Code allocated to one area to disarm another area.
Partitioning Options 2
Item Location Option Default New
Partitioning Options 2 0501 1 = Reserved
2 = User codes allowed to arm/disarm both
areas at same time (Code [0][#])
4 = Reserved
8 = Reserved
0
19
19.1
19.1.1
19.1.2
144 en | Partitioning Control Panel
2017.10 | 03 | F.01U.298.026 Installation Guide Bosch Security Systems, Inc.
