2 – User Code Allowed to Arm/Disarm Both Areas at the Same Time
If this option is selected, any user allocated to both areas can arm or disarm both areas at the
same time without entering the code at each area codepad.
If the user arms both areas at the same time and Option 1 is selected in Location 500, only an
Arm Report for Area 2 is sent.
If the user disarms both areas at the same time and Option 1 is selected in Location 500, only
a Disarm Report for Area 1 is sent.
See also
– Arm or Disarm both Areas at the Same Time, page 51
Partition Allocations
You can allocate up to 16 zones to each zone for the control panel. The 16 locations for each
area are represented by the zone indicators on the ICON codepad. You can assign any zone to
either area or both Area 1 and Area 2 to become a common zone.
Zones programmed as common zones report to the base station receiver on group zero (Area
1 – Group 1 and Area 2 – Group 2). Zones allocated to only one area report on the
corresponding group number. Common zones, other than 24-Hour zone types, do not activate
an alarm until both areas are armed in either AWAY Mode or STAY Mode 1.
Zone, user code, and codepad should be assigned to the correct area to operate. If a user
code is assigned to an area only, the user code can only operate the assigned area on this
area’s codepad. For user code and authority level, refer to User Code Priority, page 89.
Example:
Two methods to arm/disarm both areas at the same time:
– [User Code] + [0][# / *]: this method requires to allocate the same user code to both
areas as a common user code, then you can arm/disarm both areas at the same time with
any area codepad. Refer to Arm or Disarm both Areas at the Same Time, page 51 for more
information.
– [User Code] + [# / *]: this method requires to allocate the same user code to both areas
as a common user code, and allocate the same codepad to both areas as a common
codepad, then you can arm/disarm both areas at the same time with the common user
code and common codepad.
Two methods to arm/disarm single area:
– [User Code] + [01] / [02] + [# / *]: this method requires to allocate the same user code to
both areas as a common user code, and you can are/disarm any single area with any
codepad.
– [User Code] + [# / *]: this methods requires to allocate the user code and codepad to
either area, you can only arm/disarm the single area with corresponding user code and
codepad.
Zone Area Assignments
Item Location Default New Item Location Default New
Zone 1 Area 0502 1 Zone 2 Area 0503 1
Zone 3 Area 0504 1 Zone 4 Area 0505 1
Zone 5 Area 0506 1 Zone 6 Area 0507 1
Zone 7 Area 0508 1 Zone 8 Area 0509 1
Zone 9 Area 0510 1 Zone 10 Area 0511 1
19.2
19.2.1
Control Panel Partitioning | en 145
Bosch Security Systems, Inc. Installation Guide 2017.10 | 03 | F.01U.298.026
