To set STAY Mode 2 zones:
1. Enter the passcode and press [4][AWAY]. Three beeps sound and the STAY indicator
flashes.
2. Enter the number of the zone you want to automatically isolate and press [STAY]. The
corresponding zone indicator flashes.
3. Repeat step 2 for each zone you want to select.
Notice!
As each zone is selected to be isolated, the corresponding zone indicator flashes. If you make
a mistake, enter the incorrect zone number and press [STAY]. This zone is no longer selected
to be isolated and the zone indicator is extinguished.
This function does not work on a partitioned control panel system.
4. Press [AWAY]. Two beeps sound and the system returns to the disarmed state. The
indicators for the zones you selected and the STAY indicator are extinguished.
Example
If you want to select zones 2, 5, and 6, enter:
[1 2 3 4 4][AWAY][2][STAY][5][STAY][6][STAY] [AWAY]
You can disable selected zones to be automatically isolated for STAY Mode 2 at any time.
To disable STAY Mode 2 zones:
Enter your passcode and press [4][AWAY] [AWAY].
Turning Report Monitor Mode On and Off
Report Monitor Mode allows you to use the codepad for visual representation of data
transmissions between the control panel and the base station receiver. The transmission
sequence is also shown in this mode.
The codepad beeps once every two sec when Report Monitor Mode is active, whether the
system is in Installer’s Programming Mode or normal operating mode. The first five indicators
on the ICON codepad show the progressive steps during a transmission to the base station
receiver for Receiver 1 and 3, Indicator 9-13 for Receiver 2 and 4.
After you activate Report Monitor Mode, hold down [9] until two beeps sound to initiate a
Test Report.
Report Monitor Mode Indications
Zone indicator
Dialing event
1, 9 Telephone line seized
2, 10 Dialing phone number / Network connect
3, 11 Handshake received
4, 12 Data is being transmitted
5, 13 Kiss-off received
None Telephone line / Network released / idle
Zone Indicator 1-5 for Receiver 1 and 3, Zone Indicator 9-13 for Receiver 2 and 4.
To turn Report Monitor Mode on:
1. Enter the Installer Code and press [6][AWAY]. Three beeps sound.
2. Zone indicators turn on to indicate report events for receiver 1 and 2.
