Solution 6000
26 Bosch Security Systems 12/14 BLCC610U
User Guide
External Siren Op1
Is OFF and Ready
Press OK or MENU
The keypad will display the following when the
output is o and missing:
External Siren Op1
Is OFF and Ready
Connection Trouble
Press OK or MENU
The keypad will display the following when the
output is ON and OK:
External Siren Op1
Is ON and Ready
Press OK or MENU
The keypad will display the following when the
output is ON and missing:
External Siren Op1
Is ON and Ready
Connection Trouble
Press OK or MENU
4. Press [OK] to save and exit, or press [MENU] to exit
without saving.
Outputs > Commands >
Turn Output On/O
MENU 4-0-1
This menu allows you to turn outputs that have been
programmed by your security company on or o. These
outputs can be programmed to control outside lighting,
pool pumps, watering systems etc.
Enter programming mode (PIN + MENU) then,
1. Press [MENU] + [4] + [0] + [1].
If a valid PIN is required, the keypad will prompt you
to enter your PIN.
2. Use the [] and [] keys to select the output name
that you want to change, then press [OK] to select.
Alternatively, you can enter the output number,
then press [OK].
3. To toggle the output on or o, use the [ON] and
[OFF] keys.
The keypad will display the following when the
output is o:
External Siren Op1
Output is OFF,
To turn ON, Press ON.
To Go Back Press OK
To turn the output on, press [ON].
The keypad will display the following when the
output is on:
External Siren Op1
Output is ON,
To turn OFF, Press OFF.
To Go Back Press OK
To turn the output o, press [OFF].
4. Press [OK] to save and exit, or press [MENU] to exit
without saving.
Outputs > Commands >
Output Array
MENU 4-0-2
This menu allows master users to view the status of outputs
on the system in groups of 16. Outputs are continuously
being updated while the array is being displayed so that
real time status can be seen. The top two rows of the
display show the output number when read vertically and
the third row displays the output’s status as per below list.
N = NORMAL - O Condition
T = TRIGGERED - On Condition
F = FAULT - Overload Condition
- = DISABLED
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [4] + [0] + [2] and use the up and
down arrows to select the output group to view.
2. Use the up and down arrows at any time to move to
a new group. The keypad will display the following
output array information for outputs 1 to 16.
0000000001111111
1234567890123456
NNNNN---TF------
Press
OK or MENU
In the above example screen,
N = Outputs 01 to 05 are Normal (O)
F = Output 10 has a Fault (Overload)
T = Output 09 is Triggered (On)
- = Outputs 05 to 08 and Outputs 11 to 16 are
Disabled or Not Available
3. Press the [] key and the keypad will display the
output array information for outputs 17 to 32.
1112222222222333
7890123456789012
----------------
Press
OK or MENU
4. Use the [] and [] keys to move up and down
the output array and when nished press [OK] or
[MENU] to exit.
